TIG welding is used in the aerospace, automotive, food and beverage industry. The welding is carried out by virtue of the electric arc created between the electrode and the piece of metal to be welded. Filler metals, welding torches, non-fusible tungsten electrode: here is all our tips for TIG welding!

Important features

  • Cooling the torch
  • Handle Components
  • Max. Amperage
  • Electrode diameter capacity
  • Filler metal
  • Electrode Type
Discover our TIG welding accessories!

TIG welding: welding torch


Configurable on any MMA (Manual Metal Arc) welding machine, a manual TIG torch can be fitted, equipped with an inlet gas control valve connected directly to the argon bottle.
Since there is no a switch, the arc is triggered when it comes in contact with the tungsten electrode on the metal to be welded. It therefore requires dexterity to master the priming and starting of the welding.
The consequence of this process is the electrode's premature wear and the frequent interventions rerquired to re-ignite the tungsten. Nevertheless, it's a great method of TIG welding and only requires one purchase; the TIG torch and valve. Here's some very basic advice: don't forget to close the tap when the job is done to avoid seeing the bottle drain quickly!

A dedicated TIG substation with high-frequency ignition and the ability to choose the post and pre-gas, depending on the job offers a power that covers all possible different ranges of use. And once the post chosen, the only thing left to do is flip through the torch catalog!


Types of welding torch

Air or gas-cooled torch

Basic material for any required amperage not exceeding 150 A. Torch is able to go up to 240 A but is at risk of overheating! Max. Has an operating factor of60%.

Water or coolant-cooled torch

Recommended for amperages above 150 A, with an operating factor of 100%. This configuration requires the substation be equipped with a closed circuit with liquid tank and refrigeration system.

Parts and composition of a universal torch

Connectors, extensions and 5-pin rods need to be attached to the welding machine.

The cover is a neoprene protective sheath for a comfort of use encompassing:

  • Welding wire;
  • Control cable;
  • Gas supply hose;
  • In the case of the water-cooled torch, a hose for supplying water or cooling liquid.

The handle, which looks simlar to any gun, is designed to suit the largest number of users (universal model):

  • With manual control, the high frequency priming is activated by a switch or trigger that also controls the gas supply solenoid valve. This handle, a major player of welding, is very sollicited, which is why its spare parts will be the subject to a limited supply.


Spare and wear parts essential to the handle

At the back of the handle, the protective head that welders refer to as a cap, top or hat is screwed into the top of the handle. It is available in three models:

  • Long, for normal use, it may contain an entire tungsten;
  • Average;
  • Short, particularly useful for welding in confined spaces (eg piping, bodywork);
  • The waterproofing is achieved by a Teflon sealing joint.

At the front of the handle is:

  • A Teflon seal;
  • The diffuser, which is a copper, screwable piece;
  • The tungsten holder;
  • The ceramic nozzle (very fragile).

Be very aware that these components are calibrated according to the exact diameter of the tungsten electrode, ergo the need for spare parts on hand.

The TIG torch uses tungsten. Its diameter depends on the thickness to be welded, while its composition corresponds to the type of metal to be welded.

For demanding welders, sophisticated torches are available with swiveling handles, angled handles, adjustable handles and, for americanized purists, the famous pedal control in the case of sitting jobs.Automatic TIG welding also exists for a specific audience. For these machines, a wire reel is attached to the welding station for regular and accurate diffusion of the filler metal out of the ceramic nozzle - for regular welds on the first application (great for repeated weldings).


Characteristics of TIG welding torches

Cooling Type

Maximum AC / DC amperage *

% Operating factor

Tungsten electrode diameter

Benefits and strengths

Air (gas)

90/110 A

60%

0.5 to 1.6 mm

Light, manueverable, compact

Air (gas)

125/140 A

60%

0.5 to 2.4 mm

Standard model

Air (gas)

200/240 A

60%

0.5 to 3 mm

Professional

Liquid

200/220 A

100%

0.5 to 3.2 mm

Capacity, size based on weight and power

Liquid

210 to 330 A

100%

0.5 to 4 mm

For heavy-duty work

* AC / DC: alternating current / direct current.

Note: replacement and spare parts can sometimes be compatible with several models of torches, remember to ask about that when purchasing. This is a direct request from your wallet!

Explore the ManoMano catalogue
TIG torch

TIG welding: filler metal


Here's a small reminder of the all the applicable standards in the world:

  • NF, French Standard
  • EN, European Standard
  • DIN, German Standard
  • CE, European Conformity
  • AWS, American Welding Standard
  • BS, British Standard

These standards must be observed according to the specifications of any TIG welding project.
For the pros, in the case of the creation of a welding log, the traceability of the materials requires that the filler metals must be compatible with the welding steel(s).
The origin and the mechanical and chemical characteristics of a used TIG wire must be specified in the welding's "pedigree".

Explore the ManoMano catalogue
Filler metals

Diameter of filler metals TIG steel

Steel TIG filler metals are generally presented in 1mlengths and packaged in 1 or 5 kg cases. Diameters can range from 1 to 4 mm. Each rod is punched at one end (reference). The non-alloyed steels which are at risk of oxidization are copper- plated, but moisture protection will still be needed, especially if you want to use them for a while.

Classification of TIG

Type

Presentation

Destination

Advantages

Standard

Non alloy

Punched copper

Plumbing & Heating

Maneuverability: welding mild steels or carbon manganese

EN 1668

Low alloy

Punched copper

Boilers

Thin sheets

Smooth weld cord and easy to insert

EN ISO 636-A

Stainless steel 308

Punching

Stainless steel welding 304 or 304

Good control of the fusion. Suitable for food and organic acids

EN 12072

Stainless steel 316

Punching

Stainless steel welding 316 or 316Ll

Good fusion control, adapted to corrosive environment

EN 12072

Aluminum

/

Aluminum and aluminum magnesiate welding at 3%

AC Welding, Marine Construction

EN ISO 18273

Aluminum bronze

/

Welding alloys based on copper

Heterogeneous joints or galvanized steel

EN 14640

Note: Special filler metals are also available for tool welding,hard facing (cutting tools) and DUPLEX (stainless steel with a austenitic-ferritic structure: bendable and resistance to corrosion).

Non-fusible tungsten electrodes

"Tungsten" is ultimately the lead actor in TIG welding and it is bears the entire weight of the success or failure of the job. It therefore merits the greatest attention. To guide you in your choice, the table below lists the most commonly used tungsten. The color code lets you know eactly what you are dealing with.

There are four basicc types of electrodes:

End Color

Type

Section

Power

Use

Comment

Red

Tungsten Thorium at 2%

1 to 3.2 mm

CC

Steels and stainless steel

Radioactive*

Green

Pure Tungsten

1 to 4.8 mm

IT

Aluminum alloys

Stable arc and end ball shape

Yellow

1.5 lanthanum

1 to 4.8 mm

AC / DC

Steels and stainless steel

Replaces radioactive Tungsten Thorium

Grey

2% cerium

1 to 4.8 mm

CC

Carbon, stainless steel and nickel-titanium alloys

Long life expectancy

Safety note: Thoriated tungsten emits slightly radioactive material when sharpened. Good ventilation around the grinding wheel limits this risk. It is increasingly being replaced by Lanthanum tungsten (non-radioactive). The dimensions of the "needles" range from 150 to 175 mm.

Finally, a quick tip on a brilliant tool that is available: the tungsten sharpener, a kind of sophisticated electric pencil sharpener that makes it possible to prepare sharp electrode tips at the best possible angle. So much of a time saver! Lastly, always consider using proper welder's protection!

Explore the ManoMano catalogue
Grinding wheel
